HCT-21100-Vertical type Automatic Labeling Machine

Automatic single label applicator for round Bottles



Get Quote Now

Description

Vertical type Automatic Labeling Machine . It adopt vertical type transmission , vertical type labelling , more stable ,
more precise and improve working efficiency.
It’s applied to label the self-adhesive label on various largesize cylinder products, as wine bottle , zip-top can , abluent etc.
This machine is widely used in electrical , pharmacy, foodstuff, beverage, cosmetic and chemical etc industries.

Please notice : this machine can not stick double labels .

Feature
1.Adopt High stability German LEUZE / Datasensor labeling system, Panasonic or Vigor PLC , Panasonic or Riko Signal transmission system.
operation is stable and high-speed
2.Using touch-screen control operating system, simple, practical, efficient;
3.Adapt variety shape of object in top labeling;
4.Screw adjustment to suppress body movements accurately;
5.Synchronization chain mechanism ensure labeling smooth and precise calibration;
6.Advanced technology of pneumatic coding system, print the batch number and expiry clearly.(coding printer is optional)
7.Transmission-type rolling bottles, make sure the labels attached more firmly;
8.Labeling transparent label without bubble and wrinkle; (transparent sensor is optional)

Specification
1.Label width: 15- 90mm ( back paper : 15-100mm)
2.Label length:20-314mm
3.Products Size:
Diameter: φ25mm-100mm
Height: 25mm-230mm
4.Max Outside diameter of label roll: φ280mm
5.Inside diameter of label roll: φ76mm
6.Max Labeling speed: 120pcs /min
7.Accuracy of labeling:±1mm
8.Power: 220V/110V 50/60Hz 980W
9.Machine Net Weihgt : 200KG
10.Machine Dimension: 1950mm x 1100mm x 1300 mm

ACCESSORIES AND OPTIONS

PRODUCT PDF:Click here
PRODUCT OPTIONS:Not Available

FEATURES AND SPECIFICATIONS

Product Feature:

  • Adopt High stability German LEUZE labeling system, Panasonic PLC , Panasonic Signal transmission system. operation is stable and high-speed
  • Using touch-screen control operating system, simple, practical, efficient;
  • Adapt variety shape of object in top labeling;
  • Screw adjustment to suppress body movements accurately;
  • Synchronization chain mechanism ensure labeling smooth and precise calibration;
  • Advanced technology of pneumatic coding system, print the batch number and expiry clearly.
  • Transmission-type rolling bottles, make sure the labels attached more firmly;
  • Labeling transparent label without bubble and wrinkle;

Secification:

  • Label width: 15-150mm
  • Label length:20-314mm
  • Products Size:
    • Diameter: φ25mm-100mm
    • Height: 25mm-230mm
  • Max Outside diameter of label roll: φ280mm
  • Inside diameter of label roll: φ76mm
  • Max Labeling speed: 120pcs /min
  • Accuracy of labeling:±1mm
  • Power: 220V/110V 50/60Hz 980W
  • Machine Net Weight: 200KG
  • Machine Dimension: 1950mm x 1100mm x 1300 mm
